Simrad NSX 3009 Sounder Combo 9in
Details
https://www.bcf.com.au/p/simrad-nsx-3009-sounder-combo-9in/637352.htmlPromotions
Buy now, pay four interest-free payments.
- 4 simple installments
- 100% interest-free, no hidden fees
Additional Information
Product Info
Product Info
The Simrad NSX Sounder Combo puts chartplotter, sonar and marine networking technology at your fingertips. The ultimate sounder for offshore fishing and boating, each unit has a HD, weatherproof interface with 1KW transducer compatibility. There’s Side Scan, Down scan and Fish Reveal imaging to help locate (and catch) more fish. In-built CMAP charts help identify likely spots, with upgraded marine charts also fully supported through the NSX range.
Those travelling well into the big blue can feel comfortable with this unit installed on their vessel. It can be integrated into most marine networking systems and is compatible with radar and autopilot technology. You can also link your Simrad Companion app for accessing marine data and maps on the go, both on land and the water. A cracking sounder unit that will put you onto more fish, from game fishing to bottom bashing and everything in between.
Features
- Includes built in C-MAP discover charts for Australia and New Zealand
- Radar, autopilot and marine network compatibility
- High definition SolarMAX 9in IPS screen
- Can be integrated into NMEA2000, ethernet or wireless networking systems
- Setup wizard tool makes the interface simple and easy to use
- Simrad Companion app capabailities puts your maps and data at your fingertips
- Active 3 in 1 sonar features Side Scan and Down Scan with Fish Reveal
- Compatible with a range of 1KW transducers
- IP video support through NSX range
Product FEATURES
A new, intuitive touch screen experience
Bring navigation to life with NSX™
Full suite of Simrad® technology at your fingertips
Simple to set up, easy to manage
Tech Spec
| DIMENSIONS | 239 x 148.5 x 80.6mm |
|---|---|
| DIMENSIONS (WITH BRACKET) | 263 x 172.6 x 80.6mm |
| WEIGHT | 1.2kg |
| DISPLAY RESOLUTION | 1280 x 720 pixels |
| DISPLAY SCREEN BRIGHTNESS | 1200 nits |
| DISPLAY SIZE AND TYPE | 9" SolarMax IPS touchscreen |
| DISPLAY BACKLIGHT COLOUR | White |
| SUPPLY VOLTAGE | 12V DC |
| FUSE RATING | 3A |
| POWER CONSUMPTION | 18.8W |
| ETHERNET CONNECTIVITY | 1 Port (5-pin connector) |
| BLUETOOTH CONNECTIVITY | Internal |
| NMEA 2000 CONNECTIVITY | 1 NMEA 2000 Micro-C port, 1 LEN |
| NMEA 0183 CONNECTIVITY | No |
| WATER RESISTANCE | IPX6 and 7 |
| SONAR COMPATIBILITY | 1x 9-pin Xsonic 1kw sonar port, single channel CHIRP, 50/200 khz, HDI, Active Imaging |
