Product Info
Shimano’s Tiagra reels have re-written the rules of game fishing. As we all know, fish can be capable of fighting for hours, making long runs that really heat up a drag. Heat build-up can change your settings on you, meaning you end up with not enough pressure or at worst, a broken line.
Shimano’s Hydrothermal Drag System fixes that problem by automatically compensating for any heat build-up, maintaining the original drag setting. What’s more, the Shimano Tiagra’s pre lubricated graphite drag washer is impervious to salt water and will always operate smoothly. This is an innovative, heavy-duty reel that’s great for pulling in tough fish.
Features
- Hypothermal drag system automatically compensates for heat build-up
- 4 anti-rust bearings for saltwater durability
- Cold forged aluminum spool
- Machined aluminum frame and aluminum side plates
- Chrome plated sideplate screws
- Ratcheting drag lever
- Twin pawl anti-reverse system stops the reel from slipping
- 3.1:1 / 1.3:1 Retrieve Ratio Range
- Line Capacity 36kg/503m
- Weight - 2447g
Tech Spec
Shimano Tiagra Reel Range | ||||
---|---|---|---|---|
MODEL | TIAGRA 30WA LRS | TIAGRA 50WA LRS | TIAGRA TI30 | TIAGRA TI50W |
PART NUMBER | TI30WLRSA | TI50WLRSA | TI30A | TI50WA |
BALL BEARINGS | 4 | 4 | 4 | 4 |
GEAR RATIO | 3.9:1, 1.7:1 | 3.1:1, 1.3:1 | 3.9:1, 1.7:1 | 3.1:1, 1.3:1 |
LINE CAPACITY (MONO) | 24kg/500m | 37kg/480m | 14kg/640m | 24kg/750m |
LINE CAPACITY (BRAID) | 0.75mm/521m | 0.75mm/777m | 0.51mm/640m | 0.75mm/777m |
DRAG (KG) | 15kg | 20kg | 15kg | 20kg |
WEIGHT (G) | 1576g | 2447g | 1486g | 2447g |
